Flange adaptors

Flange adaptor BLOCKPLUS for PE/uPVC PN10/16
09.210

Datasheet
Certificates
Other Documentation
CAD / 3D Drawing

Features:

  • Flange socket with locking system for PE and uPVC pipes
  • Body and locking ring: ductile cast iron EN-GJS-500-7 (GGG50)
  • Traction ring: brass
  • Sealings: EPDM with double lip oring seal
  • Bolts A2, nuts A4
  • Coating inside and outside: potable epoxy coating ≥ 250µm according to  RAL-GZ662 (GSK)

Code Description CAD Drawing 3D Drawing Quantity
10132100 DN 50/63 PN 10/16
10132105 DN 65/75 PN 10/16
10132110 DN 80/90 PN 10/16
10132115 DN 100/110 PN 10/16
10132120 DN 125/125 PN 10/16
10132125 DN 150/160 PN 10/16
10132130 DN 200/200 PN 10/16
